Rack and Pinion Assembly - MAVAL - Hydraulic Power - Remanufactured - 95431M
Rack and Pinion Assembly - MAVAL - Hydraulic Power - Remanufactured - 95431M
SKU:95431M
MAVAL rack and pinions come turn-key ready for installation. They include, re-certified or new inner tie-rod ends, new bellows, fasteners, and the replacement of seals and O-rings. Pinion valves are performance tested and the unit's electronic solenoids are performance verified. In addition, all MAVAL remanufactured rack and pinions are centered before leaving the test stand, reducing install time. Each rack and pinion have the MAVAL part number etched into the housing as well as a serial number for traceability.
| Casting Material | Steel; Aluminum | |
| Distance Between Mounting Holes | 11.25 | IN |
| Distance Between Mounting Holes | 285.75 | MM |
| Hose Port Type | O-Ring | |
| Input Shaft Diameter | 0.63 | IN |
| Input Shaft Diameter | 15.88 | MM |
| Input Shaft Length | 3.31 | IN |
| Input Shaft Length | 84.12 | MM |
| Mounting Hole Quantity | 2 | |
| Pressure Port Thread Size | M18 x 1.5 | |
| Rack Length | 49.13 | IN |
| Rack Length | 1247.78 | MM |
| Return Port Thread Size | M16 x 1.5 | |
| Thread Length | 3.46 | IN |
| Thread Length | 87.93 | MM |
| Tie Rod Ends Included | Yes | |
| Total Turns Lock To Lock | 2.88 |
Application Info: 2007-2010 Chrysler Cirrus (Note: With Standard steering and 18 in. wheels, With Firm Feel steering and 16 in. wheels); 2007-2010 Chrysler Sebring (Body: Sedan / Note: With Standard steering and 18 in. wheels); 2011-2014 Chrysler 200 (Note: With Firm Feel steering and 16 in. wheels, With Standard steering and 18 in. wheels); 2008-2014 Dodge Avenger (Note: With Standard steering and 18 in. wheels, With Firm Feel steering and 16 in. wheels)2007-2010 Chrysler Sebring (Body: Sedan / Qualifier: with 18 (in) Tires, with Firm Feel Steering / Note: SBB); 2008-2010 Dodge Avenger (Qualifier: with 18 (in) Tires, with Firm Feel Steering / Note: SBB)
Interchange: Chrysler - 5272823AD
BBB Cross-Reference: 102-0193
Cardone Cross-Reference: 22-388
